Rated operation power at AC-3, 400 V | 0 |
---|---|
Number of main contacts as normally open contact | 0 |
Number of normally closed contacts as main contact | 0 |
Number of auxiliary contacts as normally open contact | 0 |
Number of auxiliary contacts as normally closed contact | 0 |
Rated operation current Ie at AC-3, 400 V | 0 |
Rated operation current Ie at AC-1, 400 V | 0 |
With manual on/off switch | No |
Switching capacity at AC-3, 240 V | 0 |
Initial setting | 3500 - 35000 |
End setting | 1800 - 32450 |
Max. operation pressure | 45,000 |
Number of auxiliary contacts as change-over contact | 1 |
Type of electric connection | Screw connection |
Explosion-proof | No |
Degree of protection (IP) | IP66 |
Initial value measuring range pressure | 0 |
Switch off pressure | 1.8 - 32.45 |
Rated voltage Ue at AC 50 Hz | 120 - 240 |
Rated voltage Ue at AC 60 Hz | 120 - 240 |
Rated voltage Ue at DC | 250 - 250 |
Bursting pressure | 160 |
Type of pressure connection | |
Engaging pressure | 3.5 - 35 |
Electronic version | Yes |
End value measuring range pressure | 0 |
Suitable as 2-point controller | Yes |
Suitable as limiter | No |
Suitable as guard | Yes |
Max. test pressure | 80 |
Medium temperature | 0 - 70 |
With hand operation | No |
Adjustable current range | 0 - 0 |
Pressure-switching differential | 17 |
