Additional information
Tip | Rastavna sklopka |
---|---|
In (A) | 630 |
Broj polova | 4 |
1.263,00€
Raspoloživost: Na upit
Tip | Rastavna sklopka |
---|---|
In (A) | 630 |
Broj polova | 4 |
Rated operation power at AC-3, 400 V | 0 |
---|---|
Number of auxiliary contacts as normally open contact | 0 |
Number of auxiliary contacts as normally closed contact | 0 |
Rated permanent current Iu | 630 |
Number of poles | 4 |
Rated operating voltage | 0 - 690 |
Conditioned rated short-circuit current Iq | 100 |
Degree of protection (IP), front side | IP40 |
Number of auxiliary contacts as change-over contact | 4 |
Interlockable | Yes |
Motor drive integrated | No |
Type of electrical connection of main circuit | Screw connection |
Version as emergency stop installation | No |
Type of control element | Long turning handle |
Version as main switch | Yes |
Version as safety switch | No |
Version as maintenance-/service switch | Yes |
Rated operation power at AC-23, 400 V | 400 |
Rated short-time withstand current lcw | 50 |
Colour control element | Black |
Suitable for ground mounting | Yes |
Suitable for front mounting 4-hole | Yes |
Suitable for front mounting center | Yes |
Suitable for distribution board installation | Yes |
Suitable for intermediate mounting | No |
Max. rated operation voltage Ue AC | 690 |
Motor drive optional | No |
Voltage release optional | No |
Device construction | Built-in device fixed built-in technique |
Rated permanent current at AC-21, 400 V | 630 |
Switching power at 400 V | 0 |
Version as reversing switch | No |
