Automatski osigurač C120H, 15kA, 1P, C, 63A

Additional information

Voltage type	AC
Built-in depth	73
Nominal rated current	63
Nominal rated voltage	400
Frequency	50 - 60
Release characteristic	C
Current limiting class	3
Over voltage category	4
Pollution degree	3
Width in number of modular spacings	6
Degree of protection (IP)	IP20
Number of protected poles	4
Concurrently switching N-neutral	Yes
Suitable for flush-mounted installation	No
Additional equipment possible	Yes
Number of poles (total)	4
Rated short-circuit breaking capacity Icn EN 60898 at 400 V	15
Rated short-circuit breaking capacity Icn EN 60898 at 230 V	15
Rated short-circuit breaking capacity Icu IEC 60947-2 at 230 V	30
Rated short-circuit breaking capacity Icu IEC 60947-2 at 400 V	15
