Width | 359 |
---|---|
Height | 23 |
Depth | 42 |
Input current at signal 1 | 3 |
Suitable for safety functions | No |
Number of digital inputs | 22 |
Number of digital outputs | 11 |
Time delay at signal exchange | - - - |
Voltage type of supply voltage | DC |
Supporting protocol for LON | No |
Number of HW-interfaces industrial Ethernet | 0 |
Number of HW-interfaces RS-232 | 0 |
Number of HW-interfaces RS-422 | 0 |
Number of HW-interfaces RS-485 | 1 |
Number of HW-interfaces serial TTY | 0 |
Number of HW-interfaces parallel | 0 |
Number of HW-interfaces other | 0 |
With optical interface | No |
Type of voltage (input voltage) | DC |
Supporting protocol for TCP/IP | No |
Supporting protocol for ASI | No |
Supporting protocol for PROFIBUS | No |
Supporting protocol for CAN | No |
Supporting protocol for INTERBUS | No |
Supporting protocol for KNX | No |
Supporting protocol for MODBUS | Yes |
Supporting protocol for Data-Highway | No |
Supporting protocol for DeviceNet | No |
Supporting protocol for SUCONET | No |
Supporting protocol for other bus systems | No |
Output current | 0 |
Short-circuit protection, outputs available | Yes |
Type of digital output | Other |
Type of electric connection | Plug-in connection |
Rail mounting possible | No |
Explosion safety category for gas | None |
Explosion safety category for dust | None |
Fieldbus connection over separate bus coupler possible | No |
System accessory | Yes |
Appendant operation agent (Ex ia) | No |
Appendant operation agent (Ex ib) | No |
Degree of protection (IP) | IP20 |
Supporting protocol for SERCOS | No |
Supporting protocol for INTERBUS-Safety | No |
Category according to EN 954-1 | |
Number of HW-interfaces PROFINET | 0 |
Number of HW-interfaces Wireless | 0 |
Front build in possible | No |
Rack-assembly possible | No |
Wall mounting/direct mounting | Yes |
Radio standard Bluetooth | No |
Radio standard WLAN 802.11 | No |
IO link master | No |
Performance level acc. to EN ISO 13849-1 | None |
Supporting protocol for AS-Interface Safety at Work | No |
Supporting protocol for DeviceNet Safety | No |
Supporting protocol for EtherNet/IP | No |
Supporting protocol for Foundation Fieldbus | No |
Supporting protocol for PROFINET CBA | No |
Supporting protocol for PROFINET IO | No |
Supporting protocol for PROFIsafe | No |
Supporting protocol for SafetyBUS p | No |
Supply voltage AC 50 Hz | - - - |
Supply voltage AC 60 Hz | - - - |
Supply voltage DC | 24 - 24 |
Permitted voltage at output | 24 - 24 |
Permitted voltage at input | 19.2 - 28.8 |
Type of output voltage | DC |
Digital inputs configurable | Yes |
Digital outputs configurable | Yes |
Radio standard GPRS | No |
Radio standard GSM | No |
Radio standard UMTS | No |
SIL according to IEC 61508 | None |
