Width | 102 |
---|---|
Height | 290 |
Depth | 104 |
Suitable for safety functions | Yes |
Number of analogue inputs | 8 |
Number of analogue outputs | 0 |
Input, current | Yes |
Input, voltage | Yes |
Input, resistor | No |
Input, resistance thermometer | No |
Input, thermocouple | No |
Input signal, configurable | Yes |
Output, current | No |
Output, voltage | No |
Output signal configurable | No |
Resolution of the analogue inputs | 12 |
Resolution of the analogue outputs | 0 |
Type of electric connection | Spring clamp connection |
Explosion safety category for gas | Other |
Explosion safety category for dust | Other |
Appendant operation agent (Ex ia) | Yes |
Appendant operation agent (Ex ib) | Yes |
Category according to EN 954-1 | 1 |
Performance level acc. to EN ISO 13849-1 | None |
Analog inputs configurable | Yes |
Analog outputs configurable | No |
SIL according to IEC 61508 | None |
