Additional information
Tip | Prekidač |
---|---|
In (A) | 1250 |
Tip zaštite | Micrologic 5.0 |
Broj polova | 3 |
Icu (kA) | 70 |
4.963,00€
Raspoloživost: Na upit
Tip | Prekidač |
---|---|
In (A) | 1250 |
Tip zaštite | Micrologic 5.0 |
Broj polova | 3 |
Icu (kA) | 70 |
Number of auxiliary contacts as normally open contact | 0 |
---|---|
Number of auxiliary contacts as normally closed contact | 0 |
Rated permanent current Iu | 1,250 |
Number of poles | 3 |
Overload release current setting | 500 - 1250 |
Number of auxiliary contacts as change-over contact | 0 |
Rated voltage | 690 - 690 |
Degree of protection (IP) | IP40 |
Position of connection for main current circuit | |
Motor drive integrated | No |
Type of electrical connection of main circuit | Screw connection |
Type of control element | Toggle |
Switched-off indicator available | Yes |
Rated short-circuit breaking capacity lcu at 400 V, 50 Hz | 70 |
Adjustment range short-term delayed short-circuit release | 1.5 - 10 |
Adjustment range undelayed short-circuit release | 2500 - 18750 |
Suitable for DIN rail (top hat rail) mounting | No |
Integrated earth fault protection | No |
Motor drive optional | Yes |
With under voltage release | No |
Device construction | Built-in device fixed built-in technique |
DIN rail (top hat rail) mounting optional | No |
Complete device with protection unit | Yes |
