Width | 125 |
---|---|
Height | 70 |
Colour housing | Grey |
Nominal rated voltage | 24 |
Length | 67 |
Material housing | Plastic |
Operation temperature | -5 - 60 |
With potential separation | No |
Operating voltage | 24 - 24 |
Explosion safety category for gas | None |
Explosion safety category for dust | None |
Material of contact surface | Other |
Max. current carrying capacity per I/O signal | 1 |
Max. current carrying capacity per socket | 2 |
Max. total current | 2 |
Degree of protection (IP) | IP2X |
With LED indication | Yes |
Pollution degree | 2 |
Core cross section finished cable | 0 |
Connection for NPN-sensors | Yes |
Connection type hood version | Screw connection |
Number of channels per connector slot | 16 |
Number of sensor-/actuator-slots | 1 |
Type of branch for trunk line | Hood distributor / pluggable trunk line connection |
Type of branches for sensor-/actuator cables | Other |
Thread sleeves sensor/actuator slots | Other |
Length of the preassembled cable | 0 |
Cable length configurable | Yes |
Cable screw gland for cable outer diameter | 0 - 0 |
Diameter contact female | 0 |
Connectable conductor cross section fine-strand with cable end sl. (hood vers.) | 0.09 - 1.5 |
Connectable conductor cross section fine-strand without cable end sl (hood vers) | 0.14 - 2.5 |
Connectable conductor cross section stranded (hood version) | 0.14 - 2.5 |
Number of poles sensor/actuator slots | 16 |
Fix cable version suitable for cable guide chain | No |
Type of connector for trunk line | Other |
Material insulation body | Other |
Connectable conductor cross section solid-core (hood version) | 0.14 - 2.5 |
Material contact body | Other copper alloys |
