Width | 0 |
---|---|
Height | 100 |
Depth | 150 |
Input current at signal 1 | 0 |
Suitable for safety functions | No |
Number of digital inputs | 0 |
Number of digital outputs | 16 |
Time delay at signal exchange | 10 - 12 |
Voltage type of supply voltage | DC |
Type of voltage (input voltage) | DC |
Redundancy | No |
Output current | 2 |
Short-circuit protection, outputs available | Yes |
Type of digital output | Relay |
Type of electric connection | Plug-in connection |
Explosion safety category for gas | None |
Explosion safety category for dust | None |
Appendant operation agent (Ex ia) | No |
Appendant operation agent (Ex ib) | No |
Category according to EN 954-1 | 1 |
Performance level acc. to EN ISO 13849-1 | None |
Supply voltage AC 50 Hz | 0 - 0 |
Supply voltage AC 60 Hz | 0 - 0 |
Supply voltage DC | 24 - 24 |
Permitted voltage at output | 19 - 30 |
Permitted voltage at input | 19 - 30 |
Type of output voltage | DC |
Digital inputs configurable | No |
Digital outputs configurable | No |
SIL according to IEC 61508 | None |
