Width | 60 |
---|---|
Height | 100 |
Depth | 59 |
Built-in height | 0 |
Power consumption | 0 |
Built-in width | 0 |
Modular version | Yes |
Suitable for safety functions | Yes |
Width in number of modular spacings | 0 |
Voltage type of supply voltage | AC/DC |
Power output | 25 |
Output voltage stabilized | Yes |
Type of electric connection | Screw connection |
Rail mounting possible | Yes |
Wall mounting possible | Yes |
Stabilized | Yes |
Degree of protection (IP) | IP20 |
Direct mounting possible | Yes |
1st secondary output voltage | 12 - 14.4 |
2nd secondary output voltage | 0 - 0 |
3rd secondary output voltage | 0 - 0 |
Secondary voltage adjustable | Yes |
Rated supply voltage at AC 50 Hz | 100 - 240 |
Rated supply voltage at AC 60 Hz | 100 - 240 |
Rated supply voltage at DC | 120 - 250 |
Short-circuit-proof | Yes |
Performance level acc. to EN ISO 13849-1 | None |
Max. output current 1 | 2 |
Max. output current 2 | 0 |
Max. output current 3 | 0 |
Nominal value output voltage 1 | 12 |
Nominal value output voltage 2 | 0 |
Nominal value output voltage 3 | 0 |
Nominal value output current 1 | 2 |
Nominal value output current 2 | 0 |
Nominal value output current 3 | 0 |
SIL according to IEC 61508 | None |
