Induktivni senzor XSD 80 x 80 x 40, plastični, Sn 60 mm, 24.. 48 V DC, priključci

Cijena (bez PDV-a)

172,14

Šifra artikla: XSDH607629

Raspoloživost: Na upit

Additional information

Tip

Induktivni senzor

Materijal

Plastični

Sn

60mm

Napajanje (V)

24.. 48 V DC

Voltage type DC
Cascadable No
Material housing Plastic
Suitable for safety functions No
Coating housing Other
Switching frequency 0
Switching distance 60
Number of semiconductor outputs with signalling function 0
Number of contact energized outputs with signalling function 0
Number of protected semiconductor outputs 0
Number of protected contact energized outputs 0
Type of interface for safety communication None
Type of electric connection Screw connection
Type of switching output Other
Type of switch function Breaker contact
Rated control supply voltage Us at AC 50HZ 0 - 0
Rated control supply voltage Us at AC 60HZ 0 - 0
Rated control supply voltage Us at DC 12 - 48
Explosion safety category for gas None
Explosion safety category for dust None
Construction type housing Standard construction
Max. output current at protected output 14
Mechanical mounting condition for sensor Not flat
With monitoring function downstream switching devices No
Supply voltage 24 - 48
Category according to EN 954-1 1
Type of actuation Metallic Target
Type of interface None
Width sensor 80
Compression-resistant No
Diameter sensor 0
Height of sensor 100
Length of sensor 40
Performance level acc. to EN ISO 13849-1 None
Interference resistance to magnetic fields Immune against magnetic DC-field
SIL according to IEC 61508 None
