DETEKTOR POKRETA ARGUS 220 ADVANCED

Nominal voltage	230
Mounting method	Surface mounted (plaster)
Colour	White
Model	Movement sensor
Halogen free	Yes
Surface protection	Untreated
Creep-under protection	Yes
Voltage type	AC
Switching-on delay	0
Switch-off delay	0
Frequency	50 - 50
With remote control	No
Staircase monitoring	Yes
Bridging switch	No
Suitable for wireless transmission	Yes
Material quality	Thermoplastic
Max. transmission range frontally	16
Max. transmission range sideways	14
Max. switching power	2,000
Temperature	-20 - 25
Max. starting current	16
Material	Plastic
Response value sensitivity adjustable	No
Dim function with dimmer basic element	No
Response value luminosity	3 - 1000
Suitable for C-load	No
Diameter detection range on floor	28
Remote operation	Yes
HVAC-control	No
Constant light control	No
Substation input	No
RAL-number (akin)	9,010
With signal unit	Yes
Control current	4
Teach-function for response value luminosity	No
Networkable	No
Forced switch off	No
Degree of protection (IP)	IP55
Alarm function	No
Transparent	No
Animal zone	No
Type of surface	Brilliant
Detection angle horizontal	0 - 220
Min. switch-on time	1
Max. duty cycle	8
Response value luminosity adjustable	Yes
Optimum mounting height	3
Pivoting range sensor, horizontal	-12 - 12
Pivoting range sensor, vertical	-24 - 9
Number of switching zones	112
With DALI interface	No
Sensor type	Passive infrared
